量程：10/20/30/40/50/60t
本体材质：不锈钢激光焊接
综合精度：0.03%
电缆长度：10m
|
参数 |
Specifications |
技术指标/Technique |
|
额定容量 |
Capacity |
10,20, 30, 40, 50, 60t |
|
精度等级 |
Accuracy class |
C3 |
|
输出灵敏度 |
Rated output |
2.0±0.1%mV/V |
|
零点输出 |
Zero balance |
±2%F.S. |
|
非线性 |
Non-linearity |
0.025%F.S. |
|
滞后 |
Hysteresis |
0.02%F.S. |
|
重复性 |
Repeatability |
0.02%F.S. |
|
蠕变（30min） |
Creep(30min) |
0.018%F.S. |
|
温度灵敏度漂移 |
Temp.effect on output |
0.014%F.S./10℃ |
|
零点温度漂移 |
Temp.effect on zero |
0.0125%F.S./10℃ |
|
输入电阻 |
Input impedance |
450±10Ω |
|
输出电阻 |
Output impedance |
480±10Ω |
|
绝缘电阻 |
Insulation |
≥5000MΩ/100VDC |
|
激励电压 |
Recommended excitation |
5~15V |
|
工作温度范围 |
Operation temp range |
-30~70℃ |
|
安全超载 |
Safe overload |
150%F.S. |
|
电缆线尺寸 |
Cable size |
Φ6×8m |
|
防护等级 |
IP Class |
IP68 |
