量程：1kg/2kg/3kg/5kg/10kg/20kg/30kg
本体材质：不锈钢
综合精度：0.1%
电缆长度：0.2m
|
参数 |
Specifications |
技术指标/Technique |
|
额定容量 |
Capacity |
1,2,3,5,10,20,30kg |
|
精度等级 |
Accuracy class |
0.1%F.S. |
|
输出灵敏度 |
Rated output |
1.5±0.1mV/V |
|
零点输出 |
Zero balance |
±0.05 mV/V |
|
非线性 |
Non-linearity |
0.1%F.S. |
|
滞后 |
Hysteresis |
0.1%F.S. |
|
重复性 |
Repeatability |
0.05%F.S. |
|
蠕变（30min） |
Creep(30min) |
0.05%F.S. |
|
温度灵敏度漂移 |
Temp.effect on output |
0.05%F.S./10℃ |
|
零点温度漂移 |
Temp.effect on zero |
0.05%F.S./10℃ |
|
输入电阻 |
Input impedance |
405±20Ω |
|
输出电阻 |
Output impedance |
350±10Ω |
|
绝缘电阻 |
Insulation |
≥5000MΩ/100VDC |
|
激励电压 |
Recommended excitation |
5~15V |
|
工作温度范围 |
Operation temp range |
-10~50℃ |
|
安全超载 |
Safe overload |
150%F.S. |
|
电缆线尺寸 |
Cable size |
4-Φ1×200mm |
|
防护等级 |
IP Class |
IP65 |
